Wport-W20

  • Product Code: W20
Buy Online

Overview of Characteristic

² MIPS MCU with 4MB Flash and 8MB SRAM. Run on eCos

² Support TCP/IP/Telnet /Modbus TCP Protocol

² Support UART to Ethernet/Wi-Fi Conversion, Serial Speed Upto 230400 bps

² Support STA/AP/AP+STA Mode

² Support Router or Bridge Network Working Mode.

² Support 10/100M Ethernet Auto-Negotiation

² Support Easy Configuration Through a Web Interface or PC IOTService Tool

² Support Security Protocol Such As SSL/AES/DES3

² Support  Web OTA Wirelss Upgrade

² Single +3.3V Power Supply

² Small Size:  45mm x  32mm x 8mm


Receiver Sensitivity 802.11b: -89 dBm (@11Mbps, CCK)
Operating Temp. -45~85℃
StorageTemp. -50~90℃,5~95%RH
Size 45mm x 32mm x 8mm
SDRAM 8MB
Network Protocol IP,TCP,UDP,DHCP,DNS,HTTP Server/Client,ARP, BOOTP, AutoIP, ICMP,Web socket, Telnet, FTP,TFTP, uPNP, NTP, SNMP,Modbus TCP
Standard 802.11 b/g/n
Network Mode STA/AP/STA+AP
Wi-Fi Security WEP64/WEP128/TKIP/ AES
Data Bits 5,6,7,8
Stop Bit 1,2
Check Bit None,Even,Odd,Space,Mark
Baud Rate TTL: 600 bps~230400bps
Flow Control No Flow control Hardware RTS/CTS、DSR/DTR Software Xon/ Xoffflow control
Configuration Web CLI XML import Telnet IOTManagerPC Software
Virtual Serial Windows XP/Vista/7/8/10(32bit\64bit)、Win Server 2003/2008/2012
Input Voltage 3.3VDC
Working Current ~200mA
Power <500mW
Processor MIPS
Basic Frequency 380MHz
Operating System eCos
Resource-Flash 4MB
Security Protocol SSL v3 AES 128Bit DES3
User Guide
Wport-W20 User Manual 20180109 [ Download Times: 265,  Date Update: 2018-12-19 18:17:34 ]
