HF-T60-1060T101 Equipment Specifications & Performance

This device is an industrial-grade 10.1-inch touch integrated machine powered by Android 11. It features wide-voltage power supply, wide-temperature operation, and front IP65 protection, suitable for industrial automation, IoT monitoring, and field human-machine interaction applications.

1. Core Hardware Configuration

• Motherboard Level: Industrial-grade

• Processor: RK3566 Quad-core ARM Cortex-A55, 1.8GHz

• Operating System: Android 11

• RAM: 2GB LPDDR4

• Storage: 8GB eMMC

• SD Card Expansion: Up to 64GB

2. Display & Touch Performance

• Screen Size: 10.1-inch IPS TFT LCD

• Resolution: 1024×600

• Viewing Angle: 85°/85°/85°/85°, wide viewing angle, high contrast, good color reproduction

• Brightness: 200 nits, 100-level adjustable

• Backlight Service Life: >20,000 hours

• Touch Panel: Capacitive touch, G+G tempered glass structure, full lamination process

3. Power & Environmental Reliability

• Input Voltage: 9–36V DC; recommended 12V 1A

• Operating Temperature: -30℃ to 80℃

• Storage Temperature: -30℃ to 80℃

• Operating Humidity: 10%–90% RH

• Protection: Front panel IP65, conformal coating, UV-resistant

• ESD: Air discharge ±8KV

• Certification: CE (RE Class B)

4. Interfaces & Communication

• Serial Ports: 2×RS232, 1×RS485, 1×TTL

• Ethernet: 10/100 Mbps

• Wireless: Wi-Fi 4 (2.4GHz b/g/n), Bluetooth 4.2

• USB: 2×USB Host, 1×Type-C OTG

• Others: Speaker interface, RTC (±20ppm @25℃)

• Terminal: 10Pin 3.81mm vertical socket

5. Physical & Development

• Dimensions: 290.00(W)×192.00(H)×29.50(T) mm

• Net Weight: 1095g

• Development: Android (Java/C++), SCADA (IOT Master)
