HF-WE210

  • Product Code: UART to Wi-Fi6/BLE/以太网 [HF-WE210]
Buy Online


Frequency Range WiFi：2.412GHz-2.472GHz； BLE：2.402GHz-2.480GHz
Wireless Standard 802.11 b/g/n/ax； BLE 5.1
Collocation Method AT+instruction set. SmartBLELink BLE Config SmartAPLink AP Config
Network Protocol IPv4， TCP/UDP/HTTP/TLS 1.2
Network Mode STA/AP/APSTA
Processor RISC CPU
Basic Frequency 240MHz
Operating System FreeRTOS
Temp. Range -40℃- 85℃
Internal Antenna √
I-PEX Connector √
Size (mm) 34.3±0.5mm x 25.0±0.3mm x 3.3±0.4mm
Work Voltage 3~3.6V
Current @No data 17mA
Current @Tx Peak <350mA
Resource-Flash 2MB
Resource-RAM 512KB
Interface-Ethernet Standard：802.3, PHY interface； Rate：10/100M Base-T auto negotiation
Storage Temp. -40℃- 125℃
User Guide
HF-WEXXX Module Operation Guide_20221215 [ Download Times: 337,  Date Update: 2022-12-15 18:30:33 ]
HF-WE210 Wi-Fi6_BLE_以太网三合一模块用户手册_V1.01(20240529) [ Download Times: 122,  Date Update: 2024-08-05 18:26:45 ]
Application Notes
HF-WEx00 EVB_20221220 [ Download Times: 278,  Date Update: 2022-12-20 18:51:16 ]
