HF-WE110

  • Product Code: UART to Wi-Fi/BLE/以太网 [HF-WE110]
Buy Online

Overview of Characteristic

²Support Wi-Fi IEEE802.11b/g/n and BLE5.0 Wireless Standards

²Support Ethernet 802.3 protocol, 10/100M interface

²Based on RISC SOC, 160MHz CPU, 276KB RAM, 2MB Flash

²Support UART Data Communication with Wi-Fi or BLE or Ethernet

²Support Wi-Fi STA/AP/AP+STA Mode

²Support BLE SmartBLELink Config

²Support Wi-Fi AP SmartAPLink

²Support Wireless and Remote Firmware Upgrade Function

²Support Software SDK for Develop

²Support Different Antenna Option：Internal PCB or External 1st IPEX

²Single +3.3V Power Supply

²Size: 34.3±0.5mm x 25.0±0.3mm x 4.3±0.4mm, SMT26 package

Frequency Range WiFi：2.412GHz-2.472GHz； BLE：2.402GHz-2.480GHz
Wireless Standard 802.11b/g/n； BLE 5.0
Collocation Method AT+instruction set. SmartBLELink BLE Config SmartAPLink AP Config
Network Protocol IPv4， TCP/UDP/HTTP/TLS 1.2
Network Mode STA/AP/APSTA
Processor RISC CPU
Basic Frequency 240MHz
Temp. Range -40℃- 85℃
Internal Antenna √
I-PEX Connector √
Size (mm) 34.3±0.5mm x 25.0±0.3mm x 4.3±0.4mm
Work Voltage 2.7~3.6V
Current @No data 40mA
Current @Tx Peak <350mA
Resource-Flash 2MB
Resource-RAM 276KB
Interface-Ethernet Standard：802.3, PHY interface； Rate：10/100M Base-T auto negotiation
Storage Temp. 40℃- 125℃
