Features

² Support Wi-Fi 802.11 a/b/g/n/ac/ax wireless standard, support 2.4GHz and 5GHz dual-band operation

² Support 802.15.1 BLE5.0 wireless standard, the rate is up to 2Mbps

² CPU support 320MHz, 356KB high speed RAM + 288KB normal RAM, 2MB or 8MB Flash

² Support Wi-Fi / BLE to UART data communication interface

² Support Wi-Fi STA / AP working mode

² Support Wi-Fi SoftAP SmartAPLink config

² Support Wi-Fi WeChat mini APP config

² Support Bluetooth SmartBLELink config

² Provide SDK for develop

² Support external 1 generation IPEX interface

² 3.3V single power supply

² Size: 22±0.2mm x 14.3±0.2mm x 8mm，DIP10 package
